Tannoy Revolution XT

Tannoy-Revolution-XT

Tannoy ha annunciato le ultime novità per la sua gamma di diffusori Tannoy Revolution XT. Tutti dotati dell’ultima versione del driver Dual Concentric.

La nuova serie dei diffusori Tannoy Revolution XT comprende i modelli XT 6F e XT 8F, da pavimento e un bookshelf, XT 6. Sono disponibili anche un Mini Stand-Mounter XT e un canale centrale XT C. Le finiture possono essere scelte tra Quercia e Noce.

Tannoy afferma che su questi modelli si è ridotta la distorsione e si è aumentato il controllo dei bassi. E il crossover, più semplice e lineare, promette un percorso del segnale ultra-pulito, mantenendo il maggior numero di dettagli musicali.

Caratteristiche tecniche diffusori Tannoy Revolution XT 6F

  • Recommended Amplifier Power(Watts RMS): 25 – 150
  • Continuous Power Handling (Watts Peak RMS): 75
  • Peak Power Handling (Watts): 300
  • Sensitivity (2.83 Volts @ 1 m): 90 dB
  • Nominal Impedance (Ohms): 8
  • Frequency Response (–6 dB): 38 Hz ÷ 32 kHz
  • Drive Unit: Dual Concentric™ High Frequency 25 mm (1”) Linear PEI dome with Torus Ogive WaveGuide and Omnimagnet technology; Dual Concentric™ Low Frequency 150 mm (6”) multi-fibre paper 44 mm (1.75”) voice coil; Bass Driver 150 mm (6”) multi-fibre paper pulp cone with rubber surround. 44 mm (1.75”) edge wound voice coil
  • Crossover Frequency: 250 Hz & 1.8 kHz
  • Crossover Type: Passive low loss 2nd order low pass, 1st order high pass
  • Enclosure Type: Downwards ported twin cavity coupled reflex
  • Volume: 30.7 l
  • Dimensions H x W x D (incl. plinth): 1005 x 269 x 317 mm

Caratteristiche tecniche diffusori Tannoy Revolution XT 8F

  • Recommended Amplifier Power (Watts RMS): 25 – 200
  • Continuous Power Handling (Watts Peak RMS): 100
  • Peak Power Handling (Watts): 400
  • Sensitivity (2.83 Volts @ 1 m): 91 dB
  • Nominal Impedance (Ohms): 8
  • Frequency Response (–6 dB) 34 Hz ÷ 32 kHz
  • Drive Unit: Dual Concentric™ High Frequency 25 mm (1”) Linear PEI dome with Torus Ogive WaveGuide and Omnimagnet technology; Dual Concentric™ Low Frequency 200 mm (8”) multi-fibre paper 44 mm (1.75”) voice coil; Bass Driver 200 mm (8”) multi-fibre paper pulp cone with rubber surround. 44 mm (1.75”) edge wound voice coil
  • Crossover Frequency: 250 Hz & 1.8 kHz
  • Crossover Type: Passive low loss 2nd order low pass, 1st order high pass
  • Enclosure Type: Downwards ported twin cavity coupled reflex
  • Volume: 48.8 l
  • Dimensions H x W x D (incl. plinth): 1080 x 317 x 345 mm

Caratteristiche tecniche diffusori Tannoy Revolution XT 6

  • Recommended Amplifier Power (Watts RMS): 25 – 120
  • Continuous Power Handling (Watts Peak RMS): 60
  • Peak Power Handling (Watts): 240
  • Sensitivity (2.83 Volts @ 1 m): 89 dB
  • Nominal Impedance (Ohms): 8
  • Frequency Response (–6dB): 46 Hz ÷ 32 kHz
  • Drive Unit: Dual Concentric™ High Frequency 25 mm (1”) Linear PEI dome with Torus Ogive WaveGuide and Omnimagnet technology; Dual Concentric™ Low Frequency 150 mm (6”) multi-fibre paper 44 mm (1.75”) voice coil
  • Crossover Frequency: 1.8 kHz
  • Crossover Type: Passive low loss 2nd order low pass, 1st order high pass
  • Enclosure Type: Downwards ported reflex
  • Volume: 10.8 l
  • Dimensions H x W x D (incl. plinth): 400.5 x 221 x 302 mm

Produttore: TANNOY
